HANSADESIGNO
HANSA | LIVING
HANSADESIGNO
Bath and shower faucets
Trim Kit/Single-lever
Floor standing (1 hole), DN15
• Body made of DZR brass
• protected against back-flow in domestic
use (according to DIN EN 1717)
Flow-rate at 3 bar: 20.4 / 13.2 l/min
Hot water supply: max. +65°C
Pull operated diverter
Automatic reset
– Hand shower
– Shower holder
– Shower hose (1250 mm)
• Single operating lever/handle
• Pin shape
• Hot/Cold symbols
• Limitation option for maximum temperature and
flow-rate
• Adjustable hot water stop (retrofittable)
Required sales items
HANSAVARIO Installation technology
HANSAVARIO
Installation technology
Concealed unit
Floor standing (1 hole), DN15
• Body made of DZR brass
Installation depth: 82 - 160 mm
Hot water supply: max. +90°C
• G1/2
• Rinsing plug
Bath/Shower concealed installation HANSABLUEBOX
HANSADESIGNO
Bath and shower faucets
Trim Kit/Single-lever
Wall mounted for concealed unit
• Body made of DZR brass
• BLUECLICK for an easy, screwless trim
plate installation
• BLUETUNE alignment after installation
of +/– 3,5o
Flow-rate at 3 bar: 21 / 21 l/min
Hot water supply: max. +90°C
Turn operated diverter
• Single operating lever/handle
• Pin shape
• Hot/Cold symbols
• Limitation option for maximum temperature and
flow-rate
• Adjustable hot water stop (retrofittable)
53272073
Chrome
EAN 4015474172951
Valid To: 31-03-2020
Replacements: 5327 2083
€ 2.027,00
DVGW: DW-6506CS0196, ABP: PA-IX 28816/ICC, SVGW: 1805-6754, ACS: 16 ACC LY 696
Required sales items
HANSABLUEBOX Installation technology
HANSABLUEBOX Installation technology
8000 0000
8001 0000
• Ø 35 mm ceramic cartridge for flow and tempera-
ture control
• Non-return valve(s)
• Projection: 200 mm
• Aerator type: CASCADE® - aerated
stream | CACHÉ® - hidden aerator without
housing
5328 0100
53280100
EAN 4015474186552
€ 417,00
• Pressure plug
• Consisting of: Mounting box and cover sleeve
H
A
N
S
A
D
E
S
I
G
N
O
81119573
Chrome
EAN 4015474279155
Valid To: 31-03-2020
Replacements: 8111 9593
€ 316,00
• Ø 35 mm ceramic cartridge for flow and tempera-
ture control
• Consisting of: Rosette plate frame | Square
rosette | Fastening of the function unit with
screws | Sleeve | Operating lever
