Recommended sales items
HANSADESIGNO
HANSAVIVA
5186 0173
EAN 4015474172944
4415 0130
€ 340,00
Chrome
€
Chrome
EAN 4015474238831
Recommended sales items
HANSAACTIVEJET
8437 0130
€
Chrome/Light grey
HANSADESIGNO
EAN 4057304005114
8110 9573
€ 266,00
Chrome
EAN 4015474278929
Required sales items
HANSADESIGNO
HANSA | LIVING
Shower
Shower faucets
Single-lever
Wall mounted, DN15
• Body made of DZR brass
• protected against back-flow in domestic
use (according to DIN EN 1717)
Flow-rate at 3 bar: 18 l/min
Hot water supply: max. +90°C
Valid To: 31-03-2020
Replacements: 5186 0183
• Single operating lever/handle
• Pin shape
G1/2
• Hot/Cold symbols
• Limitation option for maximum temperature and
flow-rate
• Adjustable hot water stop (retrofittable)
• Ø 35 mm ceramic cartridge for flow and tempera-
ture control
• Non-return valve(s)
ABP: P-IX (Certification requested), ACS: 16 ACC NY 205
• Eccentric coupling(s) | Cover plate(s) | Silencer(s)
418
Shower sets
Wall mounted, DN15, 915 mm
• Canbeshortened
Hot water supply: max. +65°C
– Hand shower: 3 shower sprays
– Shower rail
– Adjustable shower rail bracket
– Soap dish
– Shower holder
– Shower hose (1750 mm)
– Variable fixing points
– Anti limescale technology (easy to clean)
Shower sets
Wall mounted, 970 mm
• Canbeshortened
Flow-rate at 3 bar (with flow controller): 15 l/min
Hot water supply: max. +65°C
Hand shower size: Ø 120 mm
– Hand shower: 3 shower sprays
– Shower rail
– Soap dish
– Shower holder
– Shower hose (1750 mm)
– Variable fixing points
– Anti limescale technology (easy to clean)
163
Shower concealed installation HANSABLUEBOX
Shower faucets
Trim Kit/Single-lever
Wall mounted for concealed unit
• BLUECLICK for an easy, screwless trim
plate installation
Flow-rate at 3 bar: 22.2 l/min
Hot water supply: max. +90°C
• Single operating lever/handle
• Pin shape
• Hot/Cold symbols
• Limitation option for maximum temperature and
flow-rate
• Adjustable hot water stop (retrofittable)
Valid To: 31-03-2020
Replacements: 8110 9593
• Ø 35 mm ceramic cartridge for flow and tempera-
ture control
• Consisting of: Rosette plate frame | Square
rosette | Fastening of the function unit with
screws | Sleeve | Operating lever
• Without diverter
DVGW: DW-6506CS0196, ABP: PA-IX 28815/IB, SVGW: 1805-6754, ACS: 16 ACC LY 696
HANSABLUEBOX Installation technology
HANSABLUEBOX Installation technology
8000 0000
8001 0000
88
Issue 01/2020
