AVT I DN13–DN50

EPDM

Features & Information

AVT-I hoses were developed because of customer requirements for anti-vibration hoses withstanding a

working pressure of up to 30 bar. They are suitable for connecting pumps, boilers or surge tanks to the

water network where medium to high pressure prevails.

Length: according to customer need

length ±5

Length: according to customer need

length ±5

female

Fitting Material Options

female

Elbow

male

62 | Hoses

Hoses | 63

l

e

n

g

t

h

±

2

0

Structure

stainless steel braiding

ethylene propylene-diene monomer

Technical Specification

Max. operating

temperature

Max. temperature

Max. working pressure

Burst pressure

Tensile strength

Bending radius

Outer diameter (braided)

Inner diameter of fitting

Flow rate (300 mm, 3 bar,

open atmosphere)

Braiding

Inlet

+ outlet fittings

PLATINOX SLP DN10-DN32

AVT I 13

90°C

194°F

110°C

230°F

30 bar

435 psi

>120 bar

>1740 psi

>2000 N

90 mm

19 mm

AVT I 19

90°C

194°F

110°C

230°F

30 bar

435 psi

>120 bar

>1740 psi

>2500 N

90 mm

27 mm

AVT I 25

90°C

194°F

110°C

230°F

30 bar

435 psi

>120 bar

>1740 psi

>3000 N

110 mm

34 mm

20 mm

n/a

SST

1”

1” NPSM

1” NPT male

AVT I 32

90°C

194°F

110°C

230°F

25 bar

363 psi

>100 bar

>1450 psi

>3000 N

130 mm

42 mm

26 mm

n/a

SST

11/4”

11/4” NPSM

11/4” NPT male

AVT I 40

90°C

194°F

110°C

230°F

20 bar

290 psi

>70 bar

>1015 psi

n/a

150 mm

54 mm

32 mm

n/a

SST

11/2”

11/2” NPSM

11/2” NPT male

AVT I 50

90°C

194°F

110°C

230°F

20 bar

290 psi

>70 bar

>1015 psi

n/a

180 mm

66 mm

41 mm

n/a

SST

2”

2” NPSM

2” NPT male

CW617N

male

PLATINOX SLP DN10-DN32

10 mm

70 l/min

13.2 gpm

SST

1/2”

1/2” NPSM

1/2” NPT

male

15 mm

145 l/min

32 gpm

SST

3/4”

3/4” NPSM

3/4” NPT

Elbow

male

male

female
