130

Washplaces – Insert-series

WP.INSERT1

Mounting and connection measurements > see Page 192

440

170

Washplace, rectangular, w/h/d 485/471/321 mm, dish basin, ProShield,

sink left, with one tap hole, without overflow, shelf cabinet right, frame,

chrome steel, powder finish, white, towel rail right, white, fixing set, drain

valve, valve cap, chrome-plated, Ø 63 mm, bottle trap

Art. No.

white glazed steel shelf

5241 000 000

anthracite brown glazed

5241 000 110

steel shelf

Fittings information

Impact area approx. 109 – 139 mm from middle of tap hole.

For parameters, see page 20.

WP.INSERT2

ø 36

ø 300

45

Recommended miscellaneous

Art. No.

6719 000 899

222

344

132

Mirror, SP.300

Washplace, rectangular, w/h/d 485/471/321 mm, dish basin, ProShield,

sink right, with one tap hole, without overflow, shelf cabinet left, frame,

chrome steel, powder finish, white, towel rail left, white, fixing set, drain

valve, valve cap, chrome-plated, Ø 63 mm, bottle trap

Art. No.

white glazed steel shelf

5242 000 000

anthracite brown glazed

5242 000 110

steel shelf

Fittings information

Impact area approx. 109 – 139 mm from middle of tap hole.

For parameters, see page 20.

ø 36

ø 300

45

Recommended miscellaneous

Mirror, SP.300

Art. No.

6719 000 899

440

170

132

222

344

179

2

9

7

2

9

7

4

7

1

4

5

1

3

2

1

2

0

0

4

0

2

0

0

3

2

1

4

0

4

5

1

4

7

1
