SIZE (a x b)
4” x 2 1/2”
4” x 3”
6” x 2 1/2”
6” x 3”
A105
EXPOSED FIRE DEPT. INLET CONNECTION
CLAPPER TYPE
b
Used as an auxiliary inlet connection providing 500 GPM minimum to
supplement the fire protection water supply. Swing clapper provides full
waterway. Exposed design provides an economical method of satisfying
Fire Dept. inlet requirements.
Standard equipment:
Cast brass two-way inlet body with double drop clappers and pin lug hose
thread swivels; straight NPT outlet connection.
RELATED PRODUCTS
A81 p. 35
b
a
b
EXPOSED FIRE DEPT. INLET CONNECTION
CLAPPER TYPE
SIZE (a x b)
4” x 2 1/2”
6” x 2 1/2”
B
15 13/64”
15 13/64”
C
b
Used as an auxiliary inlet connection providing 500 GPM minimum to
supplement the fire protection water supply. Swing clapper provides full
waterway. Exposed design provides an economical method of satisfying
Fire Dept. inlet requirements.
Standard equipment:
Cast brass three-way inlet body with triple drop clappers and pin lug hose
thread swivels; straight NPT outlet connection.
RELATED PRODUCTS
Two way double clapper back
Branding: A105/1 - AUTO-SPKR,
A105/2 - STANDPIPE, A105/3 - PLAIN
Polished
Brass
Polished
Chrome
CERTIFICATIONS
LISTED 166Y
175 PSI
LISTED 166Y
300 PSI
LISTED 166Y
175 PSI
LISTED 166Y
300 PSI
A
A105
B
C
Three way triple clapper back
Branding:
A105/1 - AUTO-SPKR
A105/2 - STANDPIPE
A
9 17/64”
9 17/64”
A
LISTED
166Y
7 9/32”
8 1/32”
8 5/32”
8 23/32”
A
B
11 21/32”
12 27/32”
11 21/32”
12 7/8”
B
7 3/32”
7 3/32”
