SIMPLE ULTRA panel
H
Code
10 16 71
10 16 72
10 16 74
10 16 75
Specifications
Material Comp.
strength
Therm. Res.
A
B
m
2
K/W
mm
mm
0.50
1200
800
0.75
1200
800
1.25
1200
800
1.50
1200
800
H
Sur.
mm
m
2
32
0.98
39
0.98
54
0.96
61
0.96
EPS150
EPS150
EPS150
EPS150
10% kPa
200
200
200
200
Dimensional drawing
SIMPLE ULTRA panel, made of a rigid plastic sheet with bosses coupled with a panel
in graphite sintered polystyrene foam, CE marking according to UNI EN 13163, which
ensures the mechanical and thermal resistance characteristics, free of recycled and
Freon gas, flame propagation delay (Euroclass E reaction to fire according to UNI
EN 13501-1); suitable for installation centre distances that are multiple of 50 mm;
equipped with suitably dimensioned perimeter bosses to allow a rigid connection by
overlapping the panel’s sides, ensuring a perfect coupling and alignment between the
panels themselves and eliminating any possibility of formation of thermal bridges.
Use
The SIMPLE ULTRA panel consists of a moulded EPS sheet with bosses and covered
with a rigid plastic protective film and is designed to offer maximum simplicity of
installation of an underfloor radiant system.
• The rigid sheet covering allows a high degree of compressive strength;
• The use of an EPS sheet allows obtaining panels with the minimum thermal
conductivity possible for this material;
• The minimum conductivity, in combination with a production with exact thickness,
allows having the minimum possible insulation thickness while meeting the thermal
resistance requirements of the standard;
• The bosses, shaped with appropriate finger grip clips, allow an easy insertion of the
pipe of the system while ensuring it is held in position.
Technical characteristics
Properties
Material
Usable length
Working width
Thickness (H)
Minimum insulation thickness
Squareness
Compressive strength
at 10% deformation
Dimensional stability
(test 48h, 70 °C, 90% RH)
Water vapour resistance (μ)
Declared thermal conductivity (λ
D
)
Declared thermal resistance (R
D
)
Reaction to fire
Thermal capacity
Surface mass
Unit of
Value
Reference
Standard
Measure
Installation
Coupling
Fastening of
the pipes
Pipe centre
distance for
installation
interlocking with the first
row of perimeter bosses
on knobs, with interlocking
DN16 and 17, for
deformation DN20
50 mm
EN 13163
EN 822
EN 822
EN 823
EN 823
EN 824
EN 1604
EN12086
EN 12667
EN 12667
UNI EN 13501-1
EN 10456
-
EPS
mm
1200 ±7
mm
800 ±5
mm
32/39/54/61 ±2
mm
10/17/32/39 ±2
mm/m
≤2
kPa
≥ 150/200*
%
≤1
-
40 - 100
W/mK
0.030
m
2
K/W
0.50/0.75/1.25/1.50
Euroclass
E
kJ/kgK
1.45
Kg/m
2
0.40/0.58/0.95/1.13
www.wavin.it
Underfloor Radiant Systems - Product Guide
37
* The first value is that of the standard, referring only to the EPS. The second is the equivalent value for the bosses in EPS covered by the rigid sheet.
