Valves
Valves
PN
DN
T [°C]
e, m, p
27
e, m
Class
NPS [inch]
T [°C]
150 - 600
2 - 12
≥ 0 - ≤ +427
150 - 800
1⁄2 - 2
≥ 0 - ≤ +427
Description:
Globe valve to ANSI/ASME with flanged ends, cast steel/stainless steel body, trim
and bellows made of stainless steel, with bolted bonnet, outside screw and yoke,
sealed by graphite gland packing and metal bellows, stainless steel/graphite
gaskets.
Applications:
Petrochemical plants, chemical plants, power stations, process engineering and
general industrial applications; for thermal oil, steam, toxic and volatile fluids.
Other fluids on request.
http://shop.ksb.com/catalog/k0/en/product/ES000901
Description:
Globe valve to ANSI/ASME with threaded sockets (NPT) or socket weld ends (SW),
cast steel/stainless steel body, trim and bellows made of stainless steel, outside
screw and yoke, sealed by graphite gland packing and metal bellows, stainless
steel/graphite gaskets.
Applications:
Petrochemical plants, chemical plants, power stations, process engineering and
general industrial applications; for thermal oil, steam, toxic and volatile fluids.
Other fluids on request.
http://shop.ksb.com/catalog/k0/en/product/ES000902
Class
NPS [inch]
T [°C]
e, m
m
PN
DN
T [°C]
25/40
10 - 400
≥ -10 - ≤ +450
Description:
Globe valve to DIN/EN with flanged, butt weld or socket weld ends, with gland
packing, with on/off disc or throttling plug, rotating stem, seat/disc interface made
of wear and corrosion resistant chrome steel or chrome nickel steel.
Applications:
Industrial plants, power stations, process engineering and shipbuilding. For water
and steam. Other non-aggressive fluids such as gas or oil on request.
http://shop.ksb.com/catalog/k0/en/product/ES000339
10 - 40
15 - 400
≥ -10 - ≤ +400
Description:
Bellows-type globe valve to DIN/EN with flanged ends, body made of stainless
steel, with replaceable on/off disc or throttling plug.
Applications:
Process engineering, industry, building services, food and beverage industries, for
aggressive fluids. Other fluids on request.
http://shop.ksb.com/catalog/k0/en/product/ES000337
