34
Valves
Valves
Not available for worldwide sale
Actuator/Automation
PN
DN
T [°C]
16
25 - 300
≥ -10 - ≤ +70
Description:
Float valve to DIN/EN for controlling maximum and minimum liquid levels in tanks,
with flanged ends (DN 40-300) or threaded ends (DN 25-32), body made of nodular
cast iron; valve disc, stem, float and seat made of stainless steel.
Applications:
Water supply systems, industry and building services. For controlling water levels.
http://shop.ksb.com/catalog/k0/en/product/ES000835
PN
DN
T [°C]
16/25/40/63
15 - 150
≥ -10 - ≤ +70
Description:
Direct-acting pressure reducing valve to DIN/EN with flanged ends (DN 50-150) or
threaded ends (DN 15-50), body made of nodular cast iron; valve disc, stem and
seat made of stainless steel.
Applications:
In water supply systems for controlling downstream pressure, in fire-fighting
systems for reducing excess pressure caused by pumps, in irrigation systems,
industry and building services as an efficient protection against water hammer.
http://shop.ksb.com/catalog/k0/en/product/ES000834
PN
DN
T [°C]
16/25/40
50 - 150
≥ -10 - ≤ +70
Description:
Direct-acting pressure sustaining valve to DIN/EN with flanged ends, body made of
nodular cast iron, valve disc, stem and seat made of stainless steel.
Applications:
Controlling upstream pressure in water supply systems, irrigation systems or fire-
fighting systems, in industry and building services.
http://shop.ksb.com/catalog/k0/en/product/ES000678
