Valves

Valves

WADA LC 150

Class

NPS [inch]

T [°C]

150

1⁄2 - 8

≥ -196 - ≤ +100

Description:

Lift check valve to ANSI/ASME with flanged, butt weld or socket weld ends, made

of cast steel A351 CF3M/CF8/CF8M, with bolted cover, dash-pot function, graphite

or stainless steel/graphite gaskets.

Applications:

Natural gas liquefaction and other liquefied gases.

Lift check valves for nuclear applications

NUCA/-A/-ES, Type V

RJN

RYN

PN

DN

T [°C]

PN

DN

T [°C]

PN

DN

T [°C]

≥ -29

≥ -29

≥ -29

≤ 410

10 - 50

- ≤ +365

≤ 140

80 - 600

- ≤ +300

≤ 210

65 - 300

- ≤ +365

Description:

Lift check valve for nuclear applications, with butt weld ends, replaceable seat

(NUCA-ES), straight-way pattern, made of steel or stainless steel.

Applications:

Feed water and live steam systems.

http://shop.ksb.com/catalog/k0/en/product/ES000455

Description:

Damped lift check valve with butt weld ends, for nuclear applications, individually

selectable damping characteristic, made of steel or stainless steel.

Applications:

Feed water and live steam systems.

http://shop.ksb.com/catalog/k0/en/product/ES000459

Description:

Combined lift check/shut-off valve with butt weld ends, for nuclear applications, Y-

pattern, with gland packing or bellows, made of steel or stainless steel.

Applications:

Feed water and live steam systems.

http://shop.ksb.com/catalog/k0/en/product/ES000333

Not available for worldwide sale
