Valves
Valves
ZRS
SISTO-RSK/RSKS
SERIE 2000
PN
DN
T [°C]
PN
DN
T [°C]
PN
Class
DN
T [°C]
≥ -10
≥ -20
≤ 600
50 - 800
- ≤ +650
16
25 - 300
- ≤ +140
16/25
150/300
50 - 600
- ≤ +538
Description:
Swing check valve to DIN/EN with butt weld ends, pressure seal design, internally
mounted hinge pin, billet-forged body; seat/disc interface made of wear and
corrosion resistant Stellite.
Applications:
Industrial plants, power stations, process engineering and shipbuilding. For water
and steam. Other non-aggressive fluids such as gas or oil on request.
http://shop.ksb.com/catalog/k0/en/product/ES000396
Description:
Swing check valve to DIN/EN with flanged ends, body with or without lining, soft-
seated, no dead volumes, straight-way pattern, full bore, slanted seat, static
sealing to atmosphere; with soft rubber encapsulated pre-loaded valve disc
featuring short travel to closure.
Applications:
Building services, industry and power stations; suitable for drinking water, service
water, fluids handled in the food and beverage industry, abrasive and aggressive
products in chemical engineering and process engineering.
http://shop.ksb.com/catalog/k0/en/product/ES000397
Description:
Dual-plate check valve with single-piece, wafer-type body made of lamellar
graphite cast iron, nodular cast iron, steel, stainless steel or copper aluminium
alloy, metal/elastomer-seated or metal/metal-seated, maintenance-free,
connections to EN, ASME or JIS.
Applications:
Building services: heating, air-conditioning, water supply, irrigation, water
treatment. General processes: water, air, gas. Process engineering, chemical and
petrochemical industry, sugar industry, paper industry, water supply, desalination,
marine applications: water, air, gas, hydrocarbons.
http://shop.ksb.com/catalog/k0/en/product/ES000393
Swing check valves to ANSI/ASME
ECOLINE SCC 150-600
Class
NPS [inch]
T [°C]
ECOLINE SCF 150-600
Class
NPS [inch]
T [°C]
150 - 600
2 - 24
≥ 0 - ≤ +816
150 - 600
1⁄2 - 2
≥ 0 - ≤ +816
Description:
Swing check valve to ANSI/ASME with flanged ends, cast steel A216 WCB, Trim 8
(Stellite/13 % chrome steel) for Class 150/300/600, Trim 5 (Stellite/Stellite) for
Class 600, with bolted cover, internally mounted hinge pin (2"-12"), stainless steel/
graphite gaskets.
Applications:
Refineries, power stations, process engineering and general industry; water, steam,
oil, gas. Other fluids on request.
http://shop.ksb.com/catalog/k0/en/product/ES000776
Description:
Swing check valve to ANSI/ASME with flanged ends, forged steel A105, Trim 8
(Stellite/13 % chrome steel), reduced bore, with bolted cover, internally mounted
hinge pin.
Applications:
Industrial plants, power stations, process engineering, refineries, oil and marine
applications; for water, steam, gas, oil and other non-aggressive fluids.
Not available for worldwide sale
Actuator/Automation
≥ -196
http://shop.ksb.com/catalog/k0/en/product/ES000799
