52

Valves

Valves

KE

e, m, h, p + AMTROBOX/AMTRONIC/SMARTRONIC

e, m, h, p + AMTROBOX/AMTRONIC/SMARTRONIC

DANAÏS MTII

e, m, h, p + AMTROBOX/AMTRONIC/SMARTRONIC

PN

DN

T [°C]

10

40 - 600

≥ -20 - ≤ +200

Description:

Centred-disc butterfly valve with PFA liner for the chemical industry. With lever,

manual gearbox, pneumatic or electric actuator. With wafer-type body (T1), full-

lug body (T4) or U-section body with raised faces (T6). Connections to EN, ASME or

JIS.

Applications:

Highly corrosive fluids: toxic and highly corrosive fluids which cannot be handled

by metals or elastomers, thus requiring the sole use of PFA. Moderately corrosive

and aggressive fluids allowing the use of a PFA liner in combination with a

stainless steel valve disc. Fluids requiring absolutely safe handling.

http://shop.ksb.com/catalog/k0/en/product/ES000380

Double-offset butterfly valves

APORIS

e, m, p

DANAÏS 150

PN

DN

T [°C]

PN

Class

150

DN

T [°C]

50 - 1200

≥ -50 - ≤ +260

PN

Class

150/300

DN

T [°C]

50 - 600

≥ -50 - ≤ +260

Not available for worldwide sale

Actuator/Automation

10/16/25

100 - 2000

≥ -10 - ≤ +85

Description:

Double-offset butterfly valve with epoxy coating. Perfect shut-off in either flow

direction. Flanged ends to EN standards, body and valve disc made of nodular cast

iron.

Applications:

Shut-off or control duties; drinking water, seawater, air, water engineering.

http://shop.ksb.com/catalog/k0/en/product/ES000930

Description:

Double-offset butterfly valve, with plastomer seat (also in fire-safe design), metal

seat or elastomer seat (FKM [VITON R] or NBR [nitrile]). Lever or manual gearbox,

pneumatic, electric or hydraulic actuator. Body made of nodular cast iron, cast

steel, stainless steel, aluminium bronze or duplex stainless steel (254 SMO). Wafer-

type body (T1), full-lug body (T4), T4 suitable for downstream dismantling and

dead-end service with counterflange. Connections to EN, ASME or JIS. Fire-safe

design tested and certified to API 607. Fugitive emissions performance tested and

certified to EN ISO 15848-1. ATEX-compliant version in accordance with Directive

2014/34/EU.

Applications:

Petroleum, gas, chemical and petrochemical industry, marine applications,

transport of petroleum products and chemicals, sugar industry, geothermal

energy, shipbuilding, low-pressure steam, vacuum service, mining, corrosive fluids,

cleaning agents, highly aggressive fluids, brine, paper and pulp industry, fertilisers.

All applications requiring offset-disc butterfly valves.

http://shop.ksb.com/catalog/k0/en/product/ES000427

Description:

Double-offset butterfly valve with plastomer seat or metal seat (fire-safe), without

gland packing, maintenance-free, with lever or manual gearbox, pneumatic,

electric or hydraulic actuator, body made of steel or stainless steel. Wafer-type

body (T1), full-lug body (T4) or flanged body (T7) with flat or raised faces. Body

types T4 and T7 are suitable for dead-end service. Connections to EN, ASME or JIS.

Certified to German TA-Luft Technical Guidelines on Air Quality Control.

Applications:

Petroleum, gas, chemical and petrochemical industry, nuclear power stations,

onshore and offshore plants. Steam, vacuum and all applications requiring offset-

disc butterfly valves.

http://shop.ksb.com/catalog/k0/en/product/ES000381

≤ 25

25/50
