58

Valves

Valves

SISTO-20

e, m, p

SISTO-C

m, p

PN

DN

T [°C]

PN

DN

T [°C]

16

15 - 200

≥ -20 - ≤ +160

16

6 - 100

≥ -20 - ≤ +160

Description:

Diaphragm valve to DIN/EN with flanged ends; shut-off and sealing to atmosphere

by completely enclosed spiral-supported diaphragm; body with or without lining,

position indicator with integrated stem protection. All moving parts are separated

from the fluid by the diaphragm. Maintenance-free.

Applications:

Building services, industry and power stations; suitable for drinking water, service

water, air, oil, technical gases, fluids handled in the food and beverage industry,

abrasive and aggressive products in chemical engineering and process engineering.

http://shop.ksb.com/catalog/k0/en/product/ES000317

Description:

Diaphragm valve with butt weld ends or clamps; straight-way, Y or T pattern, or as

a multi-port valve; shut-off and sealing to atmosphere by completely enclosed

diaphragm. No dead volumes, suitable for sterilisation, SIP/CIP-compliant design,

position indicator. All moving parts are separated from the fluid by the

diaphragm. Maintenance-free.

Applications:

Biotechnology, pharmaceutical industry, sterile processes, food and beverage

industry.

http://shop.ksb.com/catalog/k0/en/product/ES000320

Diaphragm valves for nuclear applications

SISTO-20NA

e, m, p

SISTO-DrainNA

m

PN

DN

T [°C]

PN

DN

T [°C]

20

8 - 150

≥ -20 - ≤ +100

16

15 - 25

≥ -20 - ≤ +100

Description:

Diaphragm valve with butt weld ends, for nuclear applications, shut-off and

sealing to atmosphere by completely enclosed spiral-supported diaphragm. All

moving parts are separated from the fluid by the diaphragm. Maintenance-free.

Applications:

Cleaning systems, condensate and cooling water systems, waste water systems,

auxiliary systems.

http://shop.ksb.com/catalog/k0/en/product/ES000840

Description:

Diaphragm valve with butt weld ends, for nuclear applications; shut-off and

sealing to atmosphere by completely enclosed spiral-supported diaphragm. All

moving parts are separated from the fluid by the diaphragm. Maintenance-free.

Applications:

Heating systems, air-conditioning systems, auxiliary systems.

http://shop.ksb.com/catalog/k0/en/product/ES000841

Not available for worldwide sale

Actuator/Automation
