SHOWER ENCLOSURES

PAROIS

783

1950

Naray L2-E + LF

B

C

A

1950

Ura L2-E + LF-C

B

C

A

L2-E - Front shower enclosure with 1 sliding door + 1 fixed panel. To install between walls

or with 1 side panel LF. Clear glass and polished silver profile. Compensating profile 25

mm. MaxiClean treatment included.

LF - Side panel. To be combined with a L2-E or L4-E enclosure.

L2-E - Paroi frontale 1 panneau coulissant + 1 panneau fixe. Possibilit

é de montage entre

murs ou avec un côté fixe. Verre transparent et profil

é chromé brillant. Compensation de

25 mm. Traitement Maxiclean inclus.

LF - Panneau latéral. Pour combiner avec paroi L2-E ou L4-E.

L2-E - Front shower enclosure with 1 sliding door + 1 fixed panel. To install between walls

or with 1 side panel LF. Clear glass and polished silver profile. Compensating profile 100

mm. MaxiClean treatment included.

LF - Side panel. To be combined with a L2-E or L4-E enclosure.

L2-E - Paroi frontale 1 panneau coulissant + 1 panneau fixe. Possibilité de montage entre

murs ou avec un côté fixe. Verre transparent et profilé chromé brillant. Compensation de

100 mm. Traitement Maxiclean inclus.

LF - Panneau latéral. Pour combiner avec paroi L2-E ou L4-E.

Width (A)

L2-E

A

Opening (C)

360

410

460

510

560

610

660

710

760

L2-E

AM16210012M

AM16211012M

AM16212012M

AM16213012M

AM16214012M

AM16215012M

AM16216012M

LF(B)

AM16407012M

AM16407512M

AM16408012M

AM16409012M

1950

Victoria L2-E + LF

Width (A)

A

1000

1100

1200

1300

1400

1500

1600

B

700

750

800

900

Opening (C)

370

420

470

520

570

620

670

AM14510012M

AM14511012M

AM14512012M

AM14513012M

AM14514012M

AM14515012M

AM14516012M

AM14517012M

AM14518012M

1000

1100

1200

1300

1400

1500

1600

1700

1800

LF(B)

B

AM14707012M

700

AM14708012M

800

AM14709012M

900

B

C

A

L2-E - Front shower enclosure with 1 sliding door + 1 fixed panel. To install between walls

or with 1 side panel LF. Clear glass and polished silver profile.

LF - Side panel. To be combined with a L2-E enclosure.

L2-E - Paroi frontale 1 panneau coulissant + 1 panneau fixe. Possibilité de montage entre

murs ou avec un côté fixe LF. Verre transparent et profilé chromé brillant.

LF - Panneau latéral. Pour combiner avec paroi L2-E.

Width (A)

L2-E

A

Opening (C)

390

415

465

515

565

615

665

AM18610012

AM18611012

AM18612012

AM18613012

AM18614012

AM18615012

AM18616012

1000

1100

1200

1300

1400

1500

1600

LF(B)

B

AM18707012

700

AM18707512

750

AM18708012

800

AM18709012

900

Dimensions in mm.

Dimensions en mm.
